ATN OTS-35 2X Color Digital Thermal Imaging Monocular
ATN OTS-35 2X Color Digital Thermal Imaging Monocular Similar Products
ATN OTS-35 2X Color Digital Thermal Imaging Monocular Product Info
The ATN OTS-35 Thermal Imager 2x Monocular gives you full-color digital thermal imagery with 2x magnification, in a rugged, pocket-sized design that's made for easy carrying and lots of use.
The ATN OTS35 Thermal Scope is built around state-of-the-art uncooled thermal imaging technology, resulting in an thermal imaging scope that delivers superior performance, compact size, comfort of wear, and a great price. The ATN OTS-35 Heat Scope is a perfect choice for most any thermal imaging application, including home security, public safety, first responder and security operations.
Specifications for ATN Digital OTS-35 Thermal Imaging Scope:
| Video Frame Rate: | 60Hz |
| Magnification: | 2X |
| Objective Focal Length: | 50 mm |
| FOV: | 5.5° x 4.1° |
| Focus Range: | 5m to infinity |
| Exit Pupil: | 14mm |
| Eye Relief: | 28mm |
| Detector Type: | Uncooled Microbolometer |
| Spectral Response: | 7-14 μm |
| Resolution: | 320x240 |
| Pixel Size: | 25 x 25 μm |
| Thermal Sensitivity: | < 0,1°C |
| Range to Detect a Human: | 750 m |
| Output Format: | Analog PAL / NTSC |
| Display: | Color OLED matrix |
| Display Format: | SVGA, 800 x 600 pxl |
| E-ZOOM: | Yes |
| Brightness Adjustment: | Manual |
| Contrast Adjustment: | Automatic |
| Power Supply: | 2 x 3 V CR123A type battery |
| Start-Up Time: | < 5 sec |
| Operating Time w/one battery pack: | 4+ hrs |
| Operating Temperature Range: | from -30°C to +60°C |
| Waterproof: | Yes |
| Dimensions: | 139х110х58 mm |
| Weight (w/batteries): | 0.39 kg |
| Warranty: | 1 year |
Features of ATN OTS-35 Thermal Imager Scope w/ 2X Magnification:
- Compact & lightweight design
- Digital imaging
- Dual eye viewing system for long viewing sessions
- Enhanced Imaging (60hz)
- Vanadium oxide (VOx) Microbolometer Uncooled
- 800 x 600 OLED color display
- Rugged design with mil. spec optics
- Polarity single button modes: black on white, white on black, 5 different color settings
- Digital view menu functions
- Digital brightness control
- E-zoom
- Video output with RCA cable
- Operational range: -30°C to +60°C (-40°C to +80°C storage temp)
- Diopter range: +2° to -6°
- Eye relief: 28mm
- Extended battery life using two (2) CR123 lithium batteries (4-plus hours)
- One-year warranty
- Made in USA
Package Contents:
- ATN OTS-35 Digital Thermal Imaging Monocular
- Instruction Manual
- Lens Tissue
- Packing box
- Warranty card
- 2 x 3 V CR123A type battery
- Lens Cap
- Soft carrying Case
