Brother Mobile Solutions TD-4100N Desktop Barcode Network Printer
$364.49 $449.95 Save 19%
Code: KV-PR-TD4100N
MPN: TD4100N
UPC: 012502623564

Buy now, pay later! Now when you check out at OpticsPlanet with PayPal, you can apply for PayPal's 6 month no payments, no interest option through PayPal Credit. PayPal Credit available in USA only and orders must be over $99 to qualify. Click here to learn more.

Brother Mobile Solutions TD-4100N Desktop Barcode Network Printer Product Info

Brother Mobile Solutions TD-4100N Desktop Barcode Network Printer TD4100N comes with a WHQL certified Windows-based printer driver and is compatible with many third party Windows-based software applications. The TD-4100-N Desktop Barcode Network Printer prints high quality 300 dpi text, graphics and barcodes. This Brother Mobile Solutions printer is a true GDI printer that is fully compatible with Windows operating systems; including Windows 7. The TD-4100N Network Desktop Bar Code Printer by Brother Mobile Solution comes ready with everything you need to start printing. It will print on most medium to high sensitivity direct thermal media in high quality 300 dots per inch resolution. The PT-Editor software allows you to add bar codes, lines, curves, text and graphics. You can also print by typing or link to a MS Excel or MS Access database file or SQL server by selecting one or multiple records. This printer has a combination of high performance, value add and reliability. The Brother Mobile Solution, Inc TD-4100N Desktop Barcode Printer is the best value desktop barcode printer for Windows-based applications.

Specifications for Brother Mobile Solution Desktop Barcode Network Printer TD41-00N:

Model Type: Industrial Desktop Network Printer
Housing Color: Gray/White
Maximum Media Width: 4.13" (105 mm)
Maximum Printing Speed: 4.29 ips (109 mm/sec)
Maximum Print Resolution: 300 x 300 dpi (12 x 12 dots/mm)
Printing Method: Direct Thermal
Operation Modes: PC Connected (Dumb Printer, Template), Connected to Host Peripheral (Serial Interface)
Cutter: Automatic (Built-In)
Cutter Life: Up to 300,000 cuts (liner only), Up to 150,000 cuts (label and liner)
Maximum Print Width (inches): 3.88" (98.6 mm)
Minimum Print Length: 1" (25.4 mm)
Media Sensor & Position: Fixed Transmissive, Edge
Media Types: Drop-In Roll or Fanfold (rear slot) Continuous Label or Paper, Die Cut Labels, Tag Stock
Maximum Roll Size (outside diameter): 4" (101.6 mm)
Media Width: 0.7" - 4.0" (19 mm - 101.6 mm)
Media Thickness - With Adhesive: 0.003" - 0.007" (0.076mm-0.178mm)
Media Thickness - Without Adhesive: 0.003" - 0.006" (0.076mm-0.153mm)
Control Panel: On/Off, Feed, Cut
Status Indicator: LED (3 Colors)
Printer Emulation: Raster, ESC P, Template
Internal Fonts: ESC P - Helsinki, Letter Gothic Template (Bitmap & Outline) - Helsinki, Brussels, Letter Gothic
Internal Font Sizes: ESC P - 21, 28, 44, 56, 88, 120 dots Template (Bitmap) - 21, 28 dots Template (Outline) - 35 - 380 dots (20 sizes)
Internal Font Styles: ESC P - Bold, Italic, Underline Template - Bold, Italic, Vertical, Outline, Shadow, Outline/Shadow
Memory: 2 MB
Memory for Transferred Data (number): Up to 99 Template Files
Symbols for Windows ( No. of Clip arts in P-touch Editor): 1379
Multiple Copies: Up to 9,999 Copies (PT-Editor)
Mirror Printing: Yes
Vertical Printing: Yes
Rotate Printing: Yes
Date/Time Stamp: Through PC
Bar-codes Types: Linear - Code39, ITF (I-2/5), UPC-A, UPC-E, EAN8, EAN13, Codabar (NW-7), Code128, UCC/EAN128, Postnet, Laser Bar Code, ISBN-2, ISBN-5, GS1 DataBar (RSS) 2-Dimensional - PDF417, QR Code, Micro QR Code, Data Matrix, Maxicode
Microsoft Add-ins: Office 2000/2003/2007
Database File Compatibility: *.csv, *.txt, *.mdb, *.xls and Microsoft SQL Server
Software: BRAdmin Light 1.14, P-touch PT-Editor 5.0, Transfer Manager 2.1, Transfer Express, Library 2.1
Networking: 10/100 Print Server Built-in
Interface: USB (1.1 or 2.0), Serial (RS-232C), Ethernet (10/100 Base - TX)
Compatibility: PC
Operating System: Windows 2000 Professional/XP/7, Windows Vista ,Windows Server 2003/2008
Carton Contents: Printer, Power Cord, USB Cable, CD, RD Starter Roll - Continuous Length Label (7 m or 22.97'), RD Starter Roll - 2" x 1" Labels (250 labels), User Guide
Housing Dimensions: 6.8" (173mm) x 9.0" (229mm) x 6.2" (158mm)
Weight: 4.0 lbs (1.85 kg) Without RD Roll
Power Supply: 120VAC 60 Hz 1.8A
Power Switch: Mechanical
Energy Star: Yes
Warranty: 1 Year Limited Warranty

Features of Brother Mobile Solution, Inc Network Desktop Bar Code Printer TD4100N:

  • High performance, 4" wide desktop bar code printer
  • Uses Genuine Brother or most medium/high sensitivity direct thermal label, receipt and tag media
  • Fully compatible with Windows OS computers, including Windows 7
  • Bundled with PT-Editor print application design software
  • Prints high quality 300 dpi text, graphics and bar codes
  • Fast, host based printing - up to 4.3 ips
  • Reliable built-in automatic cutter
  • 10/100 Base TX Ethernet, USB 2.0 and RS-232C serial interface connectivity

Package Contents:

  • Brother Mobile Solutions TD-4100N Desktop Barcode Network Printer TD4100N
