Product Category Description:

CFC-free refrigeration systems ideal for rapid, environmentally-safe cooling. Models have brushed stainless steel and glacier white, epoxy-coated steel exterior with blue accents. Equipped with automatic one-button start-up to initiate collector and vacuum, dual LCD screens for vacuum and collector temperatures with LED “waves” to indicate proper conditions, a 22.9cm (9") condenser drain hose, and a 7.6cm (3") diameter stainless steel port for connection of drying accessories. All models feature a red alarm light to indicate any abnormal system events such as power failure or improper line voltage supply, a moisture sensor that detects moisture in the collector chamber area, a vacuum break valve that bleeds air into the system when power to dryer or vacuum pump is shut off, and a rear-mounted RS-232 port. Collector cools to –50°C (–58°F). Models include hot gas defrost and switch with automatic hot gas shut-off when collector coil reaches 65°C (149°F).

The stoppering tray dryer has three 42Wx30.5Dcm (161/2x12") shelves for either batch samples or bulk product processing and three probes for monitoring sample or shelf temperature. The optional purge valve, located between the pump and the condenser, helps to extend pump life, prevent back streaming of vacuum pump, and minimize the chance of contamination of samples if power is interrupted.

The 115V models and 12L 208/230V models are ETL and ETL-C listed. All 208/230V models are CE marked.

Ordering Information: Models include a three-wire cord with either a 20A plug (115V models) or a 15A plug (230V models) and a 1.9cm (3/4") I.D. vacuum hose with two clamps for connection to a vacuum pump. All models require a minimum 144L/min. vacuum pump for operation. All models are also available with an optional fluoropolymer resin-coated collector chamber ideal for processes involving corrosive compounds. For vacuum pumps, models with coated collector, and models with international electrical configurations, contact our sales representative.

Specifications for Labconco FreeZone Freeze Dry Systems, Console Models with Stoppering Tray Dryer, Labconco 7758520 6 L Models Console With Stoppering Tray Dryer:

Description:		Console with Stoppering Tray Dryer
Electrical*:		115V, 60Hz, 12.4A
Shipping Weight, kg (lbs.):		340 (750)
Labconco No.:		7758520
Condenser, 12 L Model:		3/4 hp
Water Removal Capacity, 6 L Model:		4 L/24 hrs.
Water Removal Capacity, 12 L Model:		8 L/24 hrs.
Dimensions, Stoppering Tray Dryer:		81.3W x 62.4D x 68.8H cm (32 x 2419/32 x 273/32")

(Please note that the description and stock photo may not correspond to the specific model listed above)
