Product Discontinued by Manufacturer

Steiner eOptics Laser Devices Aiming Laser Sight DBAL-I2 w/ Infrared Pointer (835nm) (<50mW) & Infrared Pointer/Illuminator (835nm) (<200mW) has been discontinued by Steiner eOptics and is no longer available. Our product experts have helped us select these available replacements below. You can also explore other items in the IR Laser Sights category yourself to try and find the perfect replacement for you!

Steiner eOptics Laser Devices Aiming Laser Sight DBAL-I2 w/ Infrared Pointer (835nm) (<50mW) & Infrared Pointer/Illuminator (835nm) (<200mW) Product Info

Steiner eOptics Aiming Laser DBAL-I2 w/ Infrared Pointer (835nm) (<50mW), Infrared Pointer/Illuminator (835nm) (<200mW) is the cutting-edge replacement for the AN/PEQ-2A combining an infrared laser pointer and infrared pointer/illuminator in a lightweight, rugged metal housing. The Steiner eOptics Laser Sight from DBAL-I2 series provides the same functionality as AN/PEQ-2A. This Laser by Steiner eOptics is smaller and lighter and also significantly shorter and leaves more rail space for other accessories. Aiming Laser Sight by Steiner eOptics mirrors the AN/PEQ-2A activation switch options. Built to perform under the most rigorous conditions and survive the harshest environments, the Laser Device DBAL-I2 Laser Sight provides operators with a critical tool for use with night vision devices.

Specifications for Steiner eOptics DBAL-I2 Laser System:

Laser Specifications
Laser Type:
  • IR Pointer: Class IIIb
  • IR Pointer/Illuminator: Class IIIb
Power Output (Hi / Lo):
  • IR Pointer: <50mW / <1mW
  • IR Pointer/Illuminator: <200mW / <5mW
Wavelength:
  • IR Pointer: 835nm
  • IR Pointer/Illuminator: 835nm
Full Angle Beam Divergence:
  • IR Pointer: 0.3 mrad
  • IR Pointer/Illuminator: 0.5 - 75 mrad
Range/Visibility (Night/Day):
  • IR Pointer: 2000m
  • IR Pointer/Illuminator: 5000m
Temperature:
  • IR Pointer: -40°C to +51°C
  • IR Pointer/Illuminator: -40°C to +51°C
Battery: One 3-volt 123A Lithium
Battery Life: Up to 5 hours continuous
Mechanical Specifications
Limited Warranty: 1 year
Material: Anodized aircraft aluminum 6061T-6
Weight (with battery): 7.2 oz / 201.3 grams
Size (LxWxH): 3.5 in x 2.75 in x 1.75 in / 8.9 cm x 7 cm x 4.4 cm
Environment: Waterproof to 20 meters

Features of Steiner eOptics DBAL I2 Aiming Laser Sight:

  • Rugged aerospace aluminum housing, MIL-SPEC Type III hardcoat anodized
  • Hi- and Lo-power modes of operation
  • Meets MIL-STD-810G requirements
  • ESD compliant for air worthiness
  • Activation / low battery indicator light (123A battery only)
  • Fully adjustable windage and elevation
  • Waterproof to 20 meters
  • Manufactured in the U.S.A.

Package Contents:

  • Steiner eOptics Laser Devices Aiming Laser Sight DBAL-I2 w/ Infrared Pointer (<50mW) and Infrared Pointer/Illuminator (<200mW)
