- Color:
- Black
- Refresh Rate:
- 25 Hz
Code: XK-THR-SS216MR-SM17004
MPN: SM17004
UPC: 840284903945
Product Info for SightMark Shade 256 2-16x15 Mini Thermal Rifle Scope
The Sightmark Shade 2-16x15 Thermal Riflescope delivers premium thermal detection in a compact, lightweight package. Designed for nighttime predator and hog hunters who demand mobility without sacrificing clarity, the Shade weighs just under 20 ounces and runs on two easy-to-find CR123A batteries. Its 256x192 thermal sensor may be modest in resolution, but it punches above its weight with a sensitive <50 mK NETD rating, perfect for detecting heat signatures in brush, fields, and thick timber.
The 15mm lens provides a wide 11 degrees field of view at 2x optical magnification, ideal for spotting and tracking fast-moving targets. The scopes revolutionary Resolution Enhancement mode further improves image clarity by sharpening edges and tightening fine detail, making the most of the sensors output when youre trying to separate an animal from the background or sift through cluttered terrain. Digital zoom up to 8x extends your reach when needed, while the high-resolution 1024x768 FLCOS display ensures crisp visuals with excellent contrast. A built-in video recorder and support for up to 256GB of storage lets you capture the action without fuss.
Crafted from durable aircraft-grade aluminum, the Shade features a streamlined Picatinny mount and intuitive controls, with onboard power or external USB support for flexible field use. Whether youre scanning a tree line or setting up for a quick shot, the Sightmark Shade 2-16x15 keeps things simple, sharp, and on target.
Specifications for SightMark Shade 256 2-16x15 Mini Thermal Rifle Scope:
| Manufacturer: | SightMark |
| Color: | Black |
| Magnification: | 2 - 16 x |
| Objective Lens Diameter: | 15 mm |
| Sensor Resolution: | 256x192 pixels |
| Display Resolution: | 1280x720 pixels |
| Refresh Rate: | 25 Hz |
| Field of View, Angle: | 11 degrees |
| Attachment Type: | Picatinny |
| Battery Type: | CR123A |
| Battery Life: | 3.5 hours |
| Operating Temperature: | -20 - 50 Celsius |
| Weight: | 19.9 oz |
| Fabric/Material: | Aluminum |
| Battery Quantity: | 2 |
Features of SightMark Shade 256 2-16x15 Mini Thermal Rifle Scope
- 256x192 Thermal Sensor - Provides reliable heat detection with <50 mK sensitivity for clear image contrast in varied conditions.
- 2x Optical / 8x Digital Magnification - Offers fast target acquisition at close range with the flexibility to zoom in for detail.
- Resolution Enhancement Mode - Sharpens thermal imagery by improving edge definition and smoothing gradients, producing a clearer, more detailed view than standard output from a 256x192 sensor.
- 15mm Objective Lens / 11 degrees Field of View - Optimized for scanning wide areas and tracking fast-moving game.
- High-Resolution 1024x768 FLCOS Display - Delivers crisp thermal imagery and excellent target definition.
- Built-In Video Recording - Capture hunts and field footage directly to a microSD card (up to 256GB).
- Power Options - Runs up to 4.4 hours on two CR123A batteries or continuously on a 5V USB power source.
- Lightweight Aluminum Housing - Streamlined aircraft-grade body keeps weight under 20 ounces for easy handling.
- Picatinny Rail Mount - Ensures fast, secure attachment to standard rifle platforms.
- All-Weather Performance - Operates from -20 C degrees to 50 C degrees for dependable performance in extreme temperatures.
- Field-Ready Simplicity - Compact, durable, and intuitive-perfect for hunters who want clarity without complication.
Package Contents:
- SightMark Shade 256 2-16x15 Mini Thermal Rifle Scope
SightMark Shade 256 2-16x15 Mini Thermal Rifle Scope Orderable Models
List of Orderable Models
- SightMark Shade 256 2-16x15 Mini Thermal Rifle Scope, Black, SM17004 , MPN: SM17004 , UPC: 840284903945 , Code: XK-THR-SS216MR-SM17004
