Armasight Apollo Thermal Imaging Clip-On System 42mm Lens,324x256 Core 30 Hz TAT253CN4APOL01
$4,595.00 $5,514.00 Save 17%
Model: Armasight Apollo Thermal Imaging Clip-On System 42mm Lens,324x256 Core 30 Hz TAT253CN4APOL01
Code: 0A-HS-ATIC256-TAT253CN4APOL01
MPN: TAT253CN4APOL01
UPC: 818470012443
Armasight Apollo Thermal Imaging Clip-On System 42mm Lens,324x256 Core 60 Hz TAT256CN4APOL01
$4,695.00 $5,634.00 Save 17%
Model: Armasight Apollo Thermal Imaging Clip-On System 42mm Lens,324x256 Core 60 Hz TAT256CN4APOL01
Code: 0A-HS-ATIC256-TAT256CN4APOL01
MPN: TAT256CN4APOL01
UPC: 818470019244
No Image Available
$4,825.00 $5,790.00 Save 17%
Objective Lens Diameter: 42 mm
Code: 0A-HS-ATIC256-TAT259CN4APOL01
MPN: TAT259CN4APOL01
UPC: 849815004311
Click to select this item for your bundle offer!
Buy Together & Save Even More!

A great way to save even more money is to purchase complementary products at the same time that you shop for what you want!

In many cases you'll be offered two additional items that you can add to your order and save, but feel free to only pick one if you want - you'll still save

As low as $4,84499 You Save 16%

Buy now, pay later! Now when you check out at OpticsPlanet with PayPal, you can apply for PayPal's 6 month no payments, no interest option through PayPal Credit. PayPal Credit available in USA only and orders must be over $99 to qualify. Click here to learn more.

Armasight Apollo 324 Thermal Imaging Clip-on System, FLIR Tau 2 324x256 (25 micron) Core, 42mm Lens Product Info

The Armasight Apollo 324-30 Clip On Thermal Imaging Scope is an innovative, lightweight, durable, and reliable thermal Clip-On system. This Thermal Clip-On System by Armasight is one of the most advanced Thermal Clip-On systems for shooting over the short distance, and which stands above the competition when it comes to clarity, versatility, reliability, function and value. Based on the proven 324x256 core, Armasight Apollo 324-30 Thermal Imaging is an ideal product for force protection, border patrol officers, police SWAT officers and special operations forces, providing users with the necessary tools to be successful in both daytime and nighttime field conditions. This thermal system converts your existing day scope to thermal and provides excellent target acquisition and aiming capabilities for the demanding sports shooter, varmint hunter, military, law enforcement, or security personnel. The thermal imaging system simply mounts in front of your own standard day optical sight. Factory bore sighted to tolerances of less than 1 MOA, no re-zeroing is required. The Arma Sight Apollo Thermal Imager allows the user to maintain consistent eye relief and shooting position allowing the user to view his own day scope's reticle. A wireless remote control unit can be placed anywhere on the user's weapon that is convenient, allowing activation of the clip-on quickly and with no fuss. The Armasight Apollo 324-30 Thermal Imaging is equipped with a locking (but quick-disconnect) mounting system which provides the user with an easy and quick way to attach/detach the device on a standard weaver or Picatinny rail. Available with 60Hz and 30Hz refresh rates that refer to the amount of times the pixels will refresh in a second, the Armasight Apollo 324 Clip On Thermal Imaging System is perfect for capturing moving targets.

Note: This product requires an installed riflescope to work properly.

Armasight TAT253CN4APOL01: Apollo Thermal Imaging Clip-On System 42mm Lens,324x256 Core 30 Hz
Armasight TAT256CN4APOL01: Apollo Thermal Imaging Clip-On System 42mm Lens,324x256 Core 60 Hz
Armasight TAT259CN4APOL01: Apollo 324,9hz Thermal Imaging Clip-on System, FLIR Tau 2, 324x256 9hz Core, 42mm Lens

Specifications for Armasight Apollo 324 Thermal Imaging Clip-on System, FLIR Tau 2 324x256 Core:

Magnification (NTSC/PAL): Unity (1x)
Objective Lens Type: Germanium
Type of Focal Plane Array: FLIR Tau 2
Pixel Array Format: 324x256
Pixel Size: 25µm
Resolution, mrad: 0.4
Display Type: AMOLED SVGA 060
Image Palettes: White Hot, Black Hot, Fusion, Rainbow, Globow, Ironbow 1, Ironbow 2, Sepia, Color 1, Color 2, Ice-Fire, Rain, and OEM Custom
Analog Input and Output Format: PAL* / NTSC
Objective F-number: 1:1
Focusing Range: 5 m to infinity
Exit Pupil Diameter: 25 mm
Battery: Two CR 123A (2x3V)
Battery Life at 20 °C (68 °F): up to 4 hr
Operating Temperature: -40 to +57°C (-40 to +134°F)
Storage Temperature: -50 to +85°C (-58 to +185°F)
Overall Dimensions: 217x70x80mm (8.5"×2.8"×3.2")
Weight (w/o Batteries): 0.7 kg (1.5 lbs)

Features of Armasight Apollo 324 Thermal Clip On:

  • Simple and Quick conversion of daytime scope to Thermal Imaging
  • Mounts in front of any daytime scope, no re-zeroing required
  • High-resolution thermal imaging
  • Compact, lightweight, durable housing
  • True magnification
  • High-end OLED display
  • Video output
  • Quick Release Mount
  • Rapid start-up
  • Up to 4 hours of operation on two lithium batteries
  • External power supply (optional)
  • Warranty: 3 Years on the System, 10 Years on the FLIR Detector

Package Contents:

  • Armasight Apollo 324 Thermal Imaging Clip-on System, FLIR Tau 2 324x256 Core
  • Light Suppressor 1
  • Light Suppressor 2
  • Light Suppressor 3
  • Light Suppressor for the Day Scope
  • Picatinny Adapter for Advanced Wireless Remote Control
  • Output lens cup
  • Mount
  • Battery Cassette
  • Video cable
  • Neck Strap
  • CR123 Lithium Battery
  • Operation and Maintenance Manual
  • Advanced Wireless remote control (AWREC)

Armasight Apollo 324 Thermal Imaging Clip-on System, FLIR Tau 2 324x256 (25 micron) Core, 42mm Lens Related Products

Armasight Apollo 324 Thermal Imaging Clip-on System, FLIR Tau 2 324x256 (25 micron) Core, 42mm Lens Unorderable Models

Factory DEMO Armasight Apollo Thermal Imaging Clip-On System 42mm Lens,324x256 Core 30 Hz TAT253CN4APOL01, MPN: TAT253CN4APOL01-DEMO, UPC: POL01-DEMO, Code: 0A-HS-ATIC256-TAT253CN4APOL01-DEMO

Armasight Apollo 324 Thermal Imaging Clip-on System, FLIR Tau 2 324x256 (25 micron) Core, 42mm Lens Comments

Customer Reviews
Helpful Positive Review Great in cold weather by Legacy Reviewer, May 7, 2014
Works even in the Chicago winter. My connected garage is unheated, so I mounted the unit on an AR, and left it overnight. 18 below in the morning, and the unit fired right up. Video out worked well, output to my Panasonic Mini DV camera. Weighs j...
Read More...
2/3 found this helpful
Read 1 Review
